500W Output Voltage and Current Both Adjustable Switch Mode Power Supply
Features:
High efficiency, high reliability
For AC power supply input global
100% full load and machine test
Pro
- Output Power
- 500W
- Output Voltage
- 0-12/24//30/36/40/48/60/70/80/90V DC Adjustable
- Output Current
- 0-33A
- Input Voltage
- AC100-120V / 200-240V
- Brand
- SSPELE
- Application
- Hospital,Engineering Project,Electric Lab,LED Lighting
- Quality
- Government Engineering,ISO9001,CE&Rohs,UL
- Payment
- T/T, L/C, Western Union,Paypal,MoneyGram
- Quantity
- 100000 PCS Per Month
- Packing
- Suitable Packing For Sea / Air Transport
- Material
- Aluminum,PCB
- Place of Origin
- Zhejiang,China
- Ripple&Noise
- 150mVp-p
Features:
- High efficiency, high reliability
- For AC power supply input global
- 100% full load and machine test
- Protection characteristics: short circuit/overload/pressure
- Built-in dc electric fan forced air cooling
- Built-in fan switch control
- PFC correction, built-in distance open/shutdown and voltage compensation signal interface
- Size: 215*115*50mm(L*W*H)
- Output Voltage Customized: 0-12/24/30/36/40/48/60/70/80/90V DC Adjustable
| model | SVA-400 -12 |
SVA-500 -80 |
SVA-500 -60 |
SVA-500 -48 |
SVA-500 -36 |
SVA-500 -24 |
SVA-500 -30 |
|
| output | Dc output voltage | 0-12V | 0-80V | 0-60V | 0-48V | 0-36V | 0-24V | 0-30V |
| Output voltage tolerance | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% | |
| Rated output current | 33A | 6.5A | 8.5A | 10A | 14A | 20A | 16A | |
| Output current range | 0-33A | 0-6.5A | 0-8A | 0-10A | 0-14A | 0-20A | 0-16A | |
| Output power | 400W | 500W | 500W | 480W | 500W | 480W | 480W | |
| Ripple and the noise | 200mVp-p | 200mVp-p | 200mVp-p | 200mVp-p | 200mVp-p | 180mVp-p | 180mVp-p | |
| Dc voltage adjustable scope | -10%,+10% | -10%,+10% | -10%,+10% | -10%,+10% | -10%,+10% | -10%,+10% | -10%,+10% | |
| Start, rise, keep time | 1.5s,50ms,20ms Loaded with | |||||||
| input | Input voltage range | 100-120VAC or 200-240VAC | ||||||
| Power factor | PF>0.95/230VAC PF>0.95/115VAC Loaded with | |||||||
| Exchange input current | 7A/115 V 3.5A/ 230 V | |||||||
| efficiency | 81% | 82% | 83% | 85.5% | 86.5% | 87% | 87% | |
| Impulse current | 18A/115V 36A/230V | |||||||
| Leakage current | <3.5mA/240VAC | |||||||
| Protection characteristics | Overload protection | 105%~135% | ||||||
| Protection way: current limiting, automatic recovery | ||||||||
| Overvoltage protection | 115%~135% | |||||||
| Protection way: hiccups, auto recovery mode | ||||||||
| environment | Working temperature, humidity | -10℃~+50℃;20%~90 %RH | ||||||
| Keep temperature, humidity | -20℃~+85℃;10%~95 %RH | |||||||
| Vibrate resistance | 10~500Hz,2G 10min./ 1 cycle time, 60 minutes, the axis | |||||||
| security | Compression sex | 3: KVAC between input and output and input and output KVAC: 1.5 to: 0.5KVAC |
||||||
| Insulation resistance | Between the input and output, the input and output, and ground: 100M Ohms/500VDC |
|||||||
| standards | Insulation resistance | Accord with UL1950,TUV EN60950 |
||||||
| EMC standard | Accord with EN55022,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11;ENV50204 |
|||||||
| other | weight | 1.0Kg | ||||||
| packaging | 20pcs/20kg/1.22CUFT | |||||||
| note | All the parameters in has not specified, all is in 230 VAC voltage input, rated load and 25℃ conditions measuring income value. Ripple and noise voltage is in 20 MHz bandwidth oscilloscope take 12 inches twisted pair end with 0.1 mu and 47 u when capacitance measurement. Tolerance is voltage setting error, the voltage adjustment rate and adjust the sum total of the current rate. The power to consider as a device installed in final equipment, this equipment must be to make sure it’s EMC index. Specific output current see output drop forehead curve. |
|||||||
